Resideo R8184G4033 Oil Burner Control Manual Trip Lever 30 Seconds 120V
Special Price $182.95 Regular Price $210.39
In stock
SKU
R8184G4033
The Resideo R8184G4033 Oil Primary Control is a sure-shot addition to oil-fired heating appliances. It is an intermittent ignition system that operates the oil burner for the right and safe burning process. It has a manual trip lever and a timing cycle of 30 seconds. This control has a high electrical rating of 7.4 A at 120 VAC, and 3.7 A at 240 VAC, and should be used with most HVAC equipment like furnaces and boilers. It measures 4.06 x 2.94 x 4.38 inches and has a gray, sturdy finish, which makes it rather universal it is functional within a range of -40°F and 130°F.
Manufacturer:
Specifications
- Type: Oil Primary Control
- Approvals and Standards: UL Component Recognized
- File no. MP268, Vol. 35 Sec. 3, CSA Certified
- File no. LR95329-1
- Ignition Type: Intermittent
- Electrical Ratings at Full Load: 7.4 A @ 120 VAC , 3.7 A @ 240 VAC
- Electrical Ratings at Locked Rotor: 44.4 A @ 120 VAC, 22.2 A @ 240 VAC
- Color: Gray
- Dimensions: 4.06" x 2.94" x 4.38"
- Temperature Range: -40°F to +130°F
- Timing Cycle: 30 Seconds
