AC Circuit Board Parts

Air conditioner circuit boards, also known as control boards, are electronic components that control various functions of an air conditioning system. Some common AC circuit board parts include:

Relays: These are used to control high-voltage circuits and can be found on the control board of an air conditioner.

Capacitors: These are electrical components that store electrical charge and are used to start the motor of an air conditioner.

Fuses: Fuses protect the air conditioner from electrical overloads.

Diodes: These are used to protect the control board from electrical surges and to ensure proper operation of the air conditioner.

Transistors: These are used in the control board of an air conditioner to control the flow of electricity to various components of the system.

Resistors: These are used in the control board of an air conditioner to regulate the flow of current to various components of the system.

All of these parts of a circuit board have the potential to malfunction, which will have an impact on how well the system functions as a whole. It is important to have an air conditioner circuit board that is in good working order to ensure the proper operation of the system.
