Resideo VC8715ZZ11 Valve Actuator SPST 24 VAC 6Sec
Special Price $136.90 Regular Price $157.43
In stock
SKU
VC8715ZZ11
The Resideo VC8715ZZ11 Valve Actuator is a high-performance recognized device that handles the valve of HVAC accurately. This actuator requires 24 VAC and has an SPST switch together with a two-position control signal, which makes it suitable for use in heating and cooling systems. It has a drive time of approximately 6 seconds and a stroke of 0.4" to give fast and accurate valve control. The actuator is built to operate in ambient temperatures of between 32°F and 150°F and is capable of operating in relative humidity of between 5% and 95% non-condensing. This product is made of a plastic casing and has a 39” cable connector, which makes it easy to retrofit into existing HVAC systems.
Manufacturer:
Specifications
- Type: Valve Actuator
- Approvals and Standards: UL Recognized, File# MH11826, CSA Certified: LR1322-367, CE Approval: 89/336/ECC, CE Approval: 73/23/EEC
- Control Signal: SPST, Two position
- Temperature Range: 32°F to 150°F
- Relative Humidity Range: 5% to 95% Non-condensing
- Drive Time: 6 sec
- Supply Voltage: 24 VAC
- Power Supply Frequency: 60 Hz
- Number of Internal Auxiliary Switches: 1
- Connection Type: Cable
- Connection Length: 39"
- Stroke: 0.4"
- Dimensions (DxWxH): 2.7"x3.7"x2.8"
- Housing Material: Plastic
