Trane RLY2547 SPDT Enclosed Relay 10A
Special Price $45.42 Regular Price $59.04
In stock
SKU
RLY2547
The Trane RLY2547 is an Enclosed Relay that is a part of HVAC systems, which are used to operate high-power circuits with low-power signals. Measuring 4.25” L x 1.5” W x 1.7” H, this relay has a surface mount construction. It operates with coil inputs of 10 to 30 VAC/DC and 120 VAC at 50/60 Hz, contact configuration SPDT. The relay can handle a contact rating of 10A at 28 VDC and can toggle voltages up to 277 VAC. It is made of gold-flashed silver cadmium oxide for ensured conductivity and durability. That it operates in just 20 milliseconds and is RoHS compliant makes it a reliable solution for ensuring the better performance of HVAC systems.
Manufacturer:
Specifications
- Length: 4.25"
- Width: 1.5"
- Height: 1.7"
- Coil Input: 10 to 30 VAC/DC
- 120 VAC
- 50/60 Hz
- Contact Configuration: SPDT
- DC Contact Rating-Relay: 10A at 28 VDC
- Frequency Rating: 50/60 Hz
- Mount: Surface
- Operating Time: 20 Millisec
- RoHS: True
- Switching Voltage: 277 VAC
- Terminal Type: Screw
- Voltage: 10 to 30 VAC/DC
- Coil Current: 28 MA at 120 VAC, 55 MA at 30 VAC, 20 MA at 30 VDC
- Coil Voltage: 120, 10 to 30V
- Current Rating: 10A
- Material: Gold Flashed Silver Cadmium Oxide
- Mounting Type: Surface
- Number of Poles: 1
- Power Rating: 1/3 HP
- Temperature Rating: -30°F to 140°F
- Type: Relay
- Weight: 0.3lb
