Step 1: Turn off and lock out all electrical power before starting.
Step 2: Mount the VFD vertically on a secure, well-ventilated surface.
Step 3: Connect the input power to the designated input terminals.
Step 4: Wire the motor leads to the output terminals as per the wiring diagram.
Step 5: Properly ground the drive to prevent electrical hazards.
Step 6: Program basic settings using the control panel according to application needs.
Step 7: Restore power, run a test, and verify proper motor operation.
