Lochinvar & A.O. Smith 100167767 Integrated Control Board

Thermostatic expansion valves are an integral part of your refrigeration unit. They are responsible for ensuring the right dosage of refrigerant is entering the cooling coil to ensure maximum efficiency in the air conditioning of the system.    These special expansion valves come with a temperature sensor that is mounted at the end of the evaporator coil. They incorporate signals from this sensor to maintain the required temperature of the HVAC system. The thermostatic expansion valve works like a precision device that can regulate the measurements of the liquid refrigerant that flows into the evaporator of your system. This regulation in the flow of the refrigerant is essential to prevent the reverse flow of the refrigerant into the compressor of your system.    Through this mechanism, the thermostatic expansion valve successfully separates the high and low pressure sides of the refrigeration/air conditioning system. The liquid refrigerant enters the expansion ...

Periodically inspect the control board for moisture exposure, dust accumulation, and heat stress marks. Confirm all plug-in connectors are firmly seated and free of corrosion. During service visits, check the stable voltage supply to prevent erratic boiler operation or control faults.

• No response or complete control failure.
• Erratic ignition sequencing or lockouts.
• Burnt relay components from power surges.
• Communication failure with sensors or display.
• Intermittent resets during operation.
