Bray Commercial DCMS24-62-P S/R Actuator 62 In-lb 0-10 VDC 24 VAC/DC

Rating:
5 5 2
2  Reviews Add Your Review
Special Price $288.68 Regular Price $320.44
In stock
SKU
DCMS24-62-P

The Bray Commercial DCMS24-62-P stands out as a compact yet robust electric actuator meticulously crafted for controlling dampers and valves within diverse HVAC systems. With its torque of 62 lb-in and its ability to operate on 24-volt AC or DC power, it is perfect for medium-sized applications. A modulating control signal (0-10VDC) improves its precision and makes it easier to precisely position the dampers to maximize airflow management. The spring-return mechanism guarantees the system's safety by promptly returning to a predetermined position in the event of a power failure. It is a great fit for a variety of indoor locations because it is protected from moisture and dust by its NEMA 1 and IP54 housing. An auxiliary switch improves system control and monitoring capabilities by offering useful feedback on valve or damper locations.

Add to Wish List
Manufacturer:
https://www.partshnc.com/media/catalog/product/d/c/dcms24-62-p.jpg
Manufacturer Name: Bray Commercial
Product Number: DCMS24-62-P
OEM Part Number: DCMS24-62-P
Product Description: 24Vac/Dc 62In# 0/10Vdc S/R Act
Weight:3.22lbs/1460.57g

Choose the best HVAC equipment parts and supplies from PartsHnC!

  • Same Day Shipping

  • Best Quality And Best Price

  • Wide Range of Inventory

  • Best Customer Service

Have More Questions or Need Help to Place The Order?
Reach us at (866)773-0907 or [email protected]

Reviews 2
Write Your Own Review
You're reviewing:Bray Commercial DCMS24-62-P S/R Actuator 62 In-lb 0-10 VDC 24 VAC/DC
Your Rating
Product Questions (2)
Customer Questions
What maintenance is required for the Bray Commercial DCMS24-62-P Actuator?

Regularly inspect wiring connections and terminal integrity to ensure stable control signals and prevent electrical faults. Check actuator mounting and linkage alignment to avoid mechanical stress and vibration damage. Keep the housing clean and free from dust or moisture ingress. Periodic functional testing ensures accurate modulation and safe operation.

What are common issues with the Bray Commercial DCMS24-62-P Actuator?

  • Signal loss or inconsistent response control input.
  • Mechanical binding or failure to fully open/close dampers.
  • Electrical connection faults causing intermittent operation.
  • Overheating or reduced torque output under continuous load conditions.

Installation Steps

Step 1: Disconnect electrical power and verify the system is fully shut down before installation.

Step 2: Remove the old actuator and inspect the valve shaft for wear or damage.

Step 3: Align the new actuator with the valve stem and mounting bracket.

Step 4: Secure all mounting hardware tightly to prevent movement during operation.

Step 5: Connect wiring according to the equipment diagram and local electrical codes.

Step 6: Restore power and test actuator movement to ensure proper opening and closing operation.
