Reznor 205444 Pressure Switch 0.30" WC

Thermostatic expansion valves are an integral part of your refrigeration unit. They are responsible for ensuring the right dosage of refrigerant is entering the cooling coil to ensure maximum efficiency in the air conditioning of the system.    These special expansion valves come with a temperature sensor that is mounted at the end of the evaporator coil. They incorporate signals from this sensor to maintain the required temperature of the HVAC system. The thermostatic expansion valve works like a precision device that can regulate the measurements of the liquid refrigerant that flows into the evaporator of your system. This regulation in the flow of the refrigerant is essential to prevent the reverse flow of the refrigerant into the compressor of your system.    Through this mechanism, the thermostatic expansion valve successfully separates the high and low pressure sides of the refrigeration/air conditioning system. The liquid refrigerant enters the expansion ...

Inspect the pressure switch regularly for cracked tubing, loose electrical terminals, or debris blocking the pressure ports. Verify proper inducer airflow and ensure the tubing remains dry and securely connected. Periodic pressure checks help maintain accurate draft sensing and safe furnace operation.

• Sticking electrical contacts causing no or continuous switching.
• Diaphragm wear or rupture leading to inaccurate pressure response.
• Clogged sensing line restricting pressure detection.
• Calibration drift causing incorrect cut-in or cut-out points.
• Intermittent operation due to wiring or connection instability.
