main product photo

Midco International 1190860 Natural Gas Pilot Assembly

Rating:
5 5 7
7  Reviews Add Your Review
Special Price $134.60 Regular Price $154.79
In stock
SKU
1190860

The Midco International 1190860 Natural Gas Pilot Assembly is an essential component in HVAC systems designed to provide reliable ignition for natural gas burners. This assembly works by emitting a small flame that ignites the gas flow, ensuring the efficient and safe operation of heating equipment. Commonly utilized in furnaces, boilers, and other gas-powered heating appliances, this pilot assembly guarantees consistent ignition, contributing to optimal performance and energy efficiency. Its sturdy design and accurate engineering assure endurance and dependability, reducing the need for frequent replacements and maintenance. By facilitating smooth ignition processes, this pilot assembly enhances overall system functionality while reducing the risk of malfunctions or shutdowns.

Add to Wish List
HVAC Controls & Electrical, Control & Sensing Devices
Manufacturer:
https://www.partshnc.com/media/catalog/product/1/1/1190860.jpg
Manufacturer Name: Midco International
Product Number: 1190860
OEM Part Number: 1190860
Product Description:  The natural gas pilot assembly is a vital component in HVAC systems, particularly in gas-powered heating units. It plays a crucial role in igniting and maintaining the pilot flame, which, in turn, is used to ignite the main burner. The primary function of the pilot assembly is to ignite the pilot flame reliably, ensuring that the main burner can be ignited when required. It includes a safety valve that prevents gas flow to the pilot when it's not ignited, enhancing safety and preventing gas leaks. Typically, it features a connection for a thermocouple, which is a safety device that monitors the pilot flame's presence. If the flame goes out, the thermocouple shuts off the gas supply to prevent gas buildup. The Midco International Natural Gas Pilot Assembly 1190860 includes a piezo igniter, which provides a simple and convenient method for manually igniting the pilot flame without the need for matches or external ignition sources. Built with durable materials like stainless steel alloys to withstand the high temperatures and harsh conditions within heating systems, ensuring a long service life. They also facilitate flame adjustment to control the size and intensity of the pilot flame, optimizing combustion efficiency. Designed for easy maintenance and replacement, should it become necessary. Ensures that the pilot flame remains steady and consistent, ready to ignite the main burner when required for heating.

The key aspects offered by Midco International Natural Gas Pilot Assembly 1190860 are:

  • Ensures consistent and dependable ignition of the pilot flame.
  • Monitors the pilot flame's presence with a thermocouple and shuts off gas in case of flame outage.
  • Designed for easy maintenance and replacement when needed.
  • Allows for flame adjustment to optimize combustion efficiency.

The natural gas pilot assembly is an integral component of gas-powered heating systems, providing reliable ignition, safety features, and durability. Its proper operation is essential for the overall performance and safety of HVAC systems.

Weight:0.94lbs/426.38g

Choose the best HVAC equipment parts and supplies from PartsHnC!

  • Same Day Shipping

  • Best Quality And Best Price

  • Wide Range of Inventory

  • Best Customer Service

Have More Questions or Need Help to Place The Order?
Reach us at (866)773-0907 or [email protected]



Reviews 7
Write Your Own Review
You're reviewing:Midco International 1190860 Natural Gas Pilot Assembly
Your Rating
Product Questions (5)
Customer Questions
What safety features are typically included in a pilot assembly, and how do they enhance system safety?

Safety features often include a safety valve and thermocouple connection to prevent gas leaks and shut off the gas supply in case of a flame outage, enhancing overall system safety.

Is manual ignition possible with a natural gas pilot assembly?

Many pilot assemblies include a piezo igniter for manual ignition without the need for external ignition sources.

Is the pilot assembly compatible with various HVAC system sizes and types?

Yes, pilot assemblies are designed to be compatible with a range of HVAC system sizes and types, offering versatility.

What maintenance is required for the Midco International 1190860 Gas Pilot Assembly?

Regularly inspect the pilot assembly for dirt, soot, or corrosion that can affect ignition. Clean the pilot tube and surrounding area carefully. Check connections and alignment to ensure proper flame. Always turn off the gas supply before performing maintenance for safety.

What are common issues with the Midco International 1190860 Gas Pilot Assembly?

  • Ignition failure or delayed lighting.
  • Weak or inconsistent pilot flame.
  • Clogged or dirty burner tip.
  • Loose or misaligned connections causing gas leaks.

Installation Steps

Step1: Turn off the gas supply and power before beginning.

Step2: Remove the access panel and the old pilot assembly from the burner area.

Step3: Clean the mounting area and fit the new pilot assembly in place.

Step4: Reconnect gas line and wiring, tighten connections, and check for leaks.

Step5: Restore gas and power, then test pilot ignition for proper and safe operation.
