Lochinvar & A.O. Smith 100284709 Trap Assembly

Rating:
5 5 6
6  Reviews Add Your Review
Special Price $185.40 Regular Price $213.21
In stock
SKU
100284709
The Lochinvar & A.O. Smith 100284709 Trap Assembly belongs to HVAC systems where it collects and harvests condensate water formed during the heating and cooling phase. This condensate due to temperature fluctuations can accumulate and cause harm if not well handled. The trap assembly functions using one of the simplest yet efficient structures known as the U-shaped bend or trap. While condensate Water rushes through the trap, some of it fills up the U-shape of the pipe preventing water from flowing back in the system. This trapped water is then judiciously drained with the wall system and any undesirable effects are averted expertly.
Add to Wish List
Lochinvar & A O Smith Water Heater Parts, Water Heater Thermostat
Manufacturer:
https://www.partshnc.com/media/catalog/product/1/0/100284709.jpg

Specifications

  • Type: Trap Assembly
  • Size: 10" X 4" X 5"
As part of the condensate drainage system in condensing water heating equipment, the Lochinvar & A.O. Smith 100284709 Trap Assembly manages moisture produced during the heating process. Positioned along the equipment’s drainage route, the assembly provides a designated point for condensate to move toward the drain connection and forms part of the appliance’s internal fluid management arrangement.

Condensate Management:
The trap assembly provides a controlled point for condensate collection and drainage. Moisture generated during operation enters the assembly from internal equipment areas and continues toward the external drainage pathway. This component specifically handles condensate rather than water circulating through the equipment’s primary heating circuit.

Water Cycle Support:
During normal water heating operation, the assembly serves the condensate portion of the equipment’s fluid management system. Its placement connects moisture collection within the appliance with the designated drainage route, keeping condensate handling separate from the primary water heating function.

Replacement Guidelines:
Consider replacement when the trap assembly has visible physical damage or its condition no longer supports its intended position within the condensate drainage arrangement. When selecting a replacement, use Lochinvar & A.O. Smith 100284709 as the identification reference and compare it with the equipment model, drainage configuration, and applicable manufacturer documentation before purchasing.

Common Signs of Wear:

  • Condensate drainage appears slower than the equipment’s normal operating condition.
  • Moisture or residue is visible around the trap assembly.
  • Mineral scale or sediment is visible inside the trap.
  • Cracks are visible on the assembly.
  • Deformation or discoloration is visible on the assembly.

Equipment Compatibility:
The Lochinvar & A.O. Smith 100284709 Trap Assembly must match the condensate trap configuration required by the equipment. Confirm the existing condensate trap configuration, equipment requirements, and part number before purchase to ensure compatibility with the intended system.

Technical Specifications:
Brand: Lochinvar & A.O. Smith
Part Number: 100284709
Product Type: Trap Assembly

Reviews 6
Write Your Own Review
You're reviewing:Lochinvar & A.O. Smith 100284709 Trap Assembly
Your Rating
Product Questions (7)
Customer Questions
What maintenance is required for the Lochinvar & A.O. Smith 100284709 Trap Assembly?

Inspect the trap assembly regularly for clogs, debris buildup, or leaks that could restrict proper condensate drainage. Clean the trap components as needed to prevent blockages and water backup. Ensure seals and connections are tight to maintain efficient and safe boiler or water heater operation.

What are common issues with the Lochinvar & A.O. Smith 100284709 Trap Assembly?

  • Leaks at connection points.
  • Clogging from debris accumulation.
  • Corrosion or rust on metal parts.
  • Improper sealing causing water or pressure loss.

Why is a condensate trap incorporated into the equipment's drainage system?

It keeps collected condensate within the dedicated drainage pathway instead of directing it through the primary water-heating circuit.

Where does condensate enter the 100284709 during equipment operation?

Condensate enters from the equipment's internal drainage path before continuing toward the designated drain connection.

What can happen if the condensate passage becomes restricted?

A restricted passage can interfere with the movement of condensate through the designated drainage route.

How does a condensate trap differ from a primary water-flow component?

A condensate trap handles drainage moisture, while primary water-flow components handle heated and circulated water within the heating process.

How does the 100284709 support condensate drainage?

It directs collected moisture through the equipment's dedicated drainage path toward the designated drain connection.

Installation Steps

Step1: Turn off power and water to the unit before beginning.

Step2: Place a bucket under the existing trap to catch water when removed.

Step3: Loosen and remove the old trap assembly and clean the connection points.

Step4: Install the new trap assembly, ensuring proper orientation and alignment.

Step5: Tighten all fittings securely to prevent leaks.

Step6: Restore water and power, then check for proper drainage and no leaks.
