Carrier 110204000 Motor 1.5HP 1140RPM 208-230/460V 3-Phase

Be the first to review this product
Special Price $3,793.59 Regular Price $4,210.88
In stock
SKU
110204000
The Carrier 110204000 is a high amplitude, 1.5 HP electric motor suitable for HVAC equipment such as rooftop units, chillers, and air handlers. The specifications of this specific motor include a steel-built frame and ball bearing consequently providing it with durability and flexibility. It rotates at 1140 RPM and can be used with an electrical supply of 208-230 volts or 460 volts in 3 phase electrical supply. The use of 60Hz power supply frequency is standard compliant with most power grid systems.
Add to Wish List
Motors & Capacitors, Motors & Components
Manufacturer:
https://www.partshnc.com/media/catalog/product/1/1/110204000_Carrier_partshnc.jpg

Specifications

  • Length: 6 "
  • Width: 6 "
  • Height: 13.5 "
  • Weight: 34.88lbs
  • Bearing Type: Ball
  • Frequency: 60 Hz
  • Horsepower: 1.5 HP
  • RPM: 1140
  • Voltage: 208-230/460V
  • Phase: 3
  • Motor Enclosure: Open Air Over
  • Frame: 56Z
  • Rotation: Reversible
Manufacturer Name: Carrier
Product Number: 110204000
OEM Part Number: 110204000
Product Description: 1.5Hp 1140Rpm 208-230/460V3ph
Weight:34.88lbs/15821.29g

Choose the best HVAC equipment parts and supplies from PartsHnC!

  • Same Day Shipping

  • Best Quality And Best Price

  • Wide Range of Inventory

  • Best Customer Service

Have More Questions or Need Help to Place The Order?
Reach us at (866)773-0907 or [email protected]

Reviews
Write Your Own Review
You're reviewing:Carrier 110204000 Motor 1.5HP 1140RPM 208-230/460V 3-Phase
Your Rating
Product Questions (2)
Customer Questions
What maintenance is required for the Carrier 110204000 Motor?

Inspect motor bearings regularly and ensure proper lubrication to reduce friction and overheating. Clean dust and debris from the motor housing and cooling fan for efficient airflow. Check electrical connections for tightness and signs of wear or corrosion. Monitor vibration and noise levels to detect early mechanical issues and prevent failure.

What are common issues with the Carrier 110204000 Motor?

  • Bearing wear leading to noise and overheating.
  • Electrical connection failure or loose wiring.
  • Motor overheating due to poor ventilation.
  • Reduced performance from winding damage or imbalance.

Installation Steps

Step 1: Disconnect electrical power and verify zero voltage before accessing the motor.

Step 2: Remove the access panel and label all wiring connections for correct reconnection.

Step 3: Disconnect power leads and mechanically loosen the motor mounting bolts.

Step 4: Remove the old motor and inspect the mounting bracket, shaft, and coupling for wear.

Step 5: Install the new motor in the same orientation and secure it firmly to the frame.

Step 6: Reconnect wiring according to configuration.

Step 7: Check shaft alignment, restore power, and test for smooth rotation and proper operation.
