AC Blower Motor Replacement

What is the use of Blower Motor?

The Blower motor is a heating and cooling system that transfers airflow from the air conditioner, heat pump, or furnace into the house. It drives heated or cooled air through the ductwork and out the vents in enclosed spaces across the house once the HVAC system has heated or cooled it.

What are the signs of a damaged blower motor?

• Weak airflow: occurs whenever the blower motor struggles to push sufficient cool air through the vents to reach the appropriate inside temperature.
• No airflow: This generally indicates that the device is utterly unusable. A competent technician can test the motor to ensure that the lack of airflow isn't caused by something else, such as a defective relay, thermostat, or fan control.
• High electricity bills: When the blower motor works extra hard to circulate air around your home adequately, you may see higher-than-normal electricity costs.
• Loud noise: A broken blower motor belt could indicate strange noises, such as squealing or screeching. Loud hammering noises are particularly concerning since they suggest that something is severely damaged.
• Dirty blower motor: The blower motors can become overheated due to the dirt and filth that collects around them. Burning odors emanating from the vent and the air conditioner system shutdown indicate that overheating is the issue.

How to replace the damaged blower motor in AC?

A blower motor is an essential part of the air conditioner system. Check your existing blower motor specifications or model number. Open the PartsFe website and search the model number in the search box to buy a suitable new blower motor for replacement. We provide all air conditioner parts and accessories at a low cost with excellent quality.

For replacement work, read the below content.

Tools for blower motor replacement:

• Screwdrivers,
• Nut drivers,
• Allen keys,
• Blower wheel puller,
• Adjustable wrench,
• Penetrating oil,
• Sand cloth,
• New blower motor,
• Digital multimeter (DMM),
• Safety glasses.

Safety rules:

• Turn off the power supply
• Wear power-resistant hand gloves

Steps to replace the blower motor in the air conditioner:

• Switch off the power supply
• Open the top and bottom panels.
• In some air conditioners, If you find the control board in the lower panel, disconnect the control board's wires and unscrew all the screws.
• Use the correct tools to disconnect all connections from the control board.
• Do it right even though it's a little challenging.
• Unscrew the upper screws to remove the blower unit from the air conditioner.
• Pull out the blower motor safely.
• Lose the shaft—Unscrews in anticlockwise directions.
• If your shaft is rusted, apply grease to it and wait for 1 - 2 minutes.
• Turn your blower wheel to the other side.
• Now, remove the screws of the bracket and cut the wires of the old blower motor.
• Remove your old air conditioner blower motor parts from the brackets.
• Clean your blower wheel and brackets.
• Replace the old blower motor with a new one.

[ Note:

1. The new blower motor must meet older blower motor specifications.
2. Clean your blower wheel and other portions correctly, then install a new blower motor. ]

• Fix the new blower motor in brackets.
• Fix all the screws and shafts properly.
• Reconnect all correct wire connections.
• Install it back in the place where it is moved from.
• Reconnect the control board and its wires.
• Close the upper and lower panels.
• Turn on the power supply.
• Observe the work of your air conditioner.
• If any problem occurs, turn off the power and call an HVAC technician.

How much does replacing an AC blower motor cost?

The average cost to replace a blower motor is $450, with costs often ranging from $250 to $800. This figure covers labor costs and additional expenses, including the cost of a new blower motor.

(NOTE: Replacement prices vary based on location, unit size, and other considerations.)

How long does an AC blower motor last?

The lifespan of an AC blower motor is between 10 and 15 years. If you maintain and clean your air conditioner blower motor parts, then it will run for a long time with better performance.
