Trane ORF01507 Orifice Fan

Be the first to review this product
Special Price $190.29 Regular Price $218.83
In stock
SKU
ORF01507
The Trane ORF01507 Orifice Fan is an airflow control component used to regulate, and stabilize air movement in packaged, and rooftop cooling equipment in HVAC systems. It is typically installed within condenser or fan sections, where it helps guide, and distribute air across heat exchange coils. It shapes, and controls the volume of air passing through the unit. It supports proper heat transfer efficiency, and balanced operating conditions. It plays an essential role in maintaining consistent condenser performance, reducing air flow irregularities and ensuring reliable thermal exchange during system operation in applications.
Add to Wish List
Motors & Capacitors, Motors & Components
Manufacturer:
https://www.partshnc.com/media/catalog/product/o/r/orf01507.jpg
Write Your Own Review
You're reviewing:Trane ORF01507 Orifice Fan
Your Rating
Product Questions (2)
Customer Questions
What maintenance is required for the Trane ORF01507 Orifice Fan?

Inspect the orifice fan regularly for dust buildup or obstructions that could restrict airflow. Clean the fan blades and surrounding area to maintain efficient performance. Ensure mounting hardware is secure and check for unusual vibrations. Always disconnect power before servicing for safety.

What are common issues with the Trane ORF01507 Orifice Fan?

  • Reduced airflow due to dust or debris.
  • Noise from unbalanced or damaged blades.
  • Motor or bearing malfunctions.
  • Vibration from loose mounting or misalignment.

Installation Steps

Step 1: Turn off power to the unit before installation.

Step 2: Remove the existing orifice or fan assembly carefully.

Step 3: Position the new orifice fan in the correct orientation and secure it with mounting hardware.

Step 4: Ensure proper alignment with the airflow path and ducting.

Step 5: Reconnect any wiring if applicable, following the diagram.

Step 6: Restore power and test the unit to verify proper airflow and operation.
